TRIDONIC MSensor G3 SSM 30 10DPI WH - 28002879
Product information "TRIDONIC MSensor G3 SSM 30 10DPI WH - 28002879"
Product description
- Sensor developed to work with the latest DALI specification
- Monitoring of ambient light and occupancy detection
- Remote control interface allowing infrared remote control interaction
- Individual adjustment of the parameters with configuration software
- Power supply via DALI line
- Shutter for preventing occupancy detection in one direction included
- Small dimensions allowing easy and inconspicuous integration in luminaries
- Wide range of accessories allowing extended application range
- SSM version (28002879) = pre-configured bundle of SFI sensor (28002119) and ACU IP20 housing (28001874)
- 5 years guarantee (conditions at https://www.tridonic.com/manufacturer-guarantee-conditions)
Housing properties
- Casing: polycarbonate, white
- Type of protection up to IP66
Note
- Tridonic DALI MSensor G3 family sensors are developed according to DALI Standard EN 62386-101 Ed.2, also known as DALI-2. To be able to use the sensor in such installation, an application controller is necessary.
- List of approved application controller can be found on our WEB page in “Downloads” in document “Application_controllers_MSensor_G3.pdf”.
EAN/UPC: 9006210709178
Country of Origin: SK
Customs tariff No.: 90318080
SCIP.: a3b1f77f-f162-4255-80ab-67d845bc4a1c
