TCI FL-EVG BCC 124 - 137947HTC
Product information "TCI FL-EVG BCC 124 - 137947HTC"
The TCI BCC 124 by TCI is an emergency current capable, ultra small and compact IP20 protected electronic multi-lamp ballast for T5/T8 and TC lamps, suitable for installation in luminaires of protection class I and II. The FL ECG is also suitable for connection to emergency equipment according to 60598-2-22. The maximum power is 24 watts.
The FL ECG has push-wire connections. The input and output terminal blocks are mounted on opposite sides. The ballast can be secured with a slot for screws (M4).
The TCI BCC 124 performs a start with pre-heating to increase the life of the lamp.
The FL ECG is protected for the case of lamp failure, end of lamp life and disconnection of the lamp (a restart with pre-heating is performed). The EMC compliance at 0 and 60 Hz operation depends on the respective luminaire manufacturer.
Downloads & Documents
Login
Electrical data
| number of channels: | 1 |
|---|---|
| energy efficiency index: | A2 |
| rated voltage: | 220-240 V |
Casing
| form type: | rectangular |
|---|---|
| max housing temperature (tc-max): | 85 °C |
| protection type: | IP20 |
| mounting: | Installation |
| environment temperature from: | -15 °C |
| environment temperature to: | 55 °C |
Photometric data
| color: | white |
|---|
Logistic data
| item category: | electronic ballasts |
|---|
Dimensions & packaging
| EAN | 8010703100596 |
|---|---|
| Length | 80 mm |
| Width | 41 mm |
| Height | 18 mm |
| Weight | 40 g |
