Airfal LED waterproof luminaire ORION IP67 1200 mm 24 Watt 3200 lm 4000 K – OR214
Airfal LED waterproof luminaire ORION IP67 1200 mm 24 Watt 3200 lm 4000 K – OR214
Shipping in 28 day(s)
€198.37
Prices incl. VAT plus shipping costs net €166.70
Product information "Airfal LED waterproof luminaire ORION IP67 1200 mm 24 Watt 3200 lm 4000 K – OR214"
LED waterproof luminaire with 24W and 3200lm
Airfal's moisture-proof luminaire ORION has a nominal output of 24 watts and a luminous flux of 3200 lumens. The efficiency is 133,34 lm / W. With its light color of 4000 K, it provides neutral white light. It has a length of 1380 mm.
IP67 protection against water and dust
The LED lumiare is made of polycarbonate and has ABS terminals including mounting flanges to facilitate installation. Thanks to its IP67 protection, the LED waterproof luminaire is protected against dust and the ingress of harmful amounts of water. In addition, the Airfal ORION luminaire has the impact strength IK09.
Ideal application areas include cold stores, warehouses, sports facilities, parking lots, public outdoor areas and generally humid environments. The life of the LED moisture-proof luminaire is 50,000 Hours.
Downloads & Documents
Login
Electrical data
| operating frequency: | 50/60 Hz |
|---|---|
| through wiring: | no |
| rated voltage: | 220-240 V |
| conformity: | CE |
| lifetime: | 50000 h |
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| form type: | linear |
| protection type: | IP67 |
| material: | polycarbonate |
| mounting: | surface mounting, ceiling mounting |
| impact resist: | IK09 |
| environment temperature from: | -20 °C |
| environment temperature to: | 40 °C |
Photometric data
| sensor: | no |
|---|---|
| dimmable: | no |
| color code: | 840 |
| color: | white |
| color temperature [Kelvin]: | 4000 |
| color rendering index [CRI]: | >80 |
| lamp type: | LED |
| lamp efficiency: | 133.34 lm/W |
| inclusive lamp: | yes |
| sensor type: | no |
| lum flux: | 3200 lm |
Dimensions & packaging
| Length | 1380 mm |
|---|---|
| Width | 81 mm |
| Height | 81 mm |
