Brumberg LED panel surface-mounted recessed MOON, white, round – 12205073 – 425143930389 - 12205073
Brumberg LED panel surface-mounted recessed MOON, white, round – 12205073 – 425143930389 - 12205073
Shipping in 7 day(s)
€40.06
Prices incl. VAT plus shipping costs net €33.66
Product information "Brumberg LED panel surface-mounted recessed MOON, white, round – 12205073 – 425143930389 - 12205073"
Brumberg MOON MINI 12205073. LED surface mounted- / recessed panel, trailing-edge phase dimmable, Round. Toolless ceiling installation by installation springs. Ceiling cut-out Installation depth 25 mm, Outer diameter 170 mm, Weight 0,250 kg, with rotattionssymmetrical, deep, wide distributed light intensity. optimal light distribution due to a plastic, opal cover. Luminous flux 1.020 lm, Power 1 x 12 W, System Efficiency 85 lm/W, Light colour warm white to daylight white, Correlated color temprature (CCT) 2.800 - 5.600 K, Colour rendering index CRI > 80, Rated life time L70/B50 at 25 °C: 25000 h, Housing material: Aluminium / Plastic, Colour: White, Permissible ambient temperature (ta): -20 °C - +25 °C, Protection class (EN 61140): II, Degree of protection (DIN EN 60529): IP20. With electronic driver, Trailing-edge phase dimmable. BRUMBERG article number: 12205073 , GTIN: 4251433930389
Downloads & Documents
Login
Electrical data
| operating frequency: | 50 Hz |
|---|---|
| through wiring: | no |
| rated voltage: | 230 V |
| conformity: | CE |
| lifetime: | 25000 h |
Casing
| ballproof: | no |
|---|---|
| form type: | round |
| protection type: | IP20 |
| material: | aluminum, plastic |
| mounting: | ceiling mounting, Installation |
| protection class: | II |
Photometric data
| radiation angle: | 110 ° |
|---|---|
| sensor: | no |
| dimmable: | yes |
| color: | white |
| color temperature [Kelvin]: | 2800-5600 |
| color rendering index [CRI]: | >80 |
| lamp type: | LED |
| lamp efficiency: | 95 lm/W |
| inclusive lamp: | yes |
| interface: | Phase cut |
| solar panel: | no |
| lum flux: | 1135 lm |
Dimensions & packaging
| Length | 19 mm |
|---|---|
| Width | 170 mm |
| Height | 19 mm |
| Weight | 242 g |
