Ledvance LED lamp T8 EM Osram SubstiTUBE Value 18.3 W/6500 K 1500 mm - 4099854038242

LEDVANCE

Ledvance LED lamp T8 EM Osram SubstiTUBE Value 18.3 W/6500 K 1500 mm - 4099854038242

Product number: 4099854038242

Immediately available

e
a g
Datasheet

€6.99


Content: 1 Stück

Prices incl. VAT plus shipping costs net €5.87

Product information "Ledvance LED lamp T8 EM Osram SubstiTUBE Value 18.3 W/6500 K 1500 mm - 4099854038242"

Cost-efficient LED tubes for electromagnetic ballasts (KVG/VVG). Product properties: LED replacement for conventional fluorescent lamps with G13 base in KVG or mains voltage. Flicker -arm according to EU 2019/2020 (SVM ≤0.4 / PSTLM ≤ 1). Individual and tandem operation on conventional ballast (0.6 m version). Glass tube. Coat silver-free and raw-compliant. Homogeneous illumination. Protection class: IP20. Product advantages: no passages thanks to glass tube. Energy saving of up to 68 % (compared to T8 fluorescent lamp at the KVG). Simple, faster and safe lamp exchange without rewiring. Full brightness without warm -up phase, therefore ideal in combination with sensors. Very high switching resistance. Also suitable for operation at low temperatures. Areas of application: general lighting in ambient temperatures of -20 ...+45 ° C. Corridore, stairs and parking garages. Industry. Warehouses. Cool and storage rooms. Applications in the household. Supermarkets and department stores. Technical equipment: Suitable for operation with low -loss and conventional ballast



ECG compatibility

Electronic transformers were all first developed for conventional halogen, fluorescent or compact fluorescent lamps and not for lamps with integrated electronic like LED lamps. Therefore, LEDVANCE is providing a list of electronic control gears (ECG) that have been tested and proven to be compatible with our range of LED lamps

Follow this link to the ECG compatibility list

Downloads & Documents

0 of 0 reviews

Leave a review!

Share your experiences with other customers.

Electrical data
operating frequency: 50/60 Hz
energy efficiency index: E
rated voltage: 220-240 V
lifetime: 30000 h
system power: 18,3
switching cycles: 200000
Casing
form type: linear
protection type: IP20
material: glass
Photometric data
dimmable: no
color temperature [Kelvin]: 6500
color rendering index [CRI]: >80
socket: G13
start time: 0,5 s
lum flux: 2200 lm
Logistic data
country of origin: China
Dimensions & packaging
EAN 4099854038242
Length 1513 mm
Width 26.7 mm
Height 26.7 mm
Weight 230 g
