Ledvance LED spotlight SPOT ADJUST 8W 930 PS DIM IP20 SI - 4058075799707
LEDVANCE
Ledvance LED spotlight SPOT ADJUST 8W 930 PS DIM IP20 SI - 4058075799707
Product number:
4058075799707
Immediately available
€28.00
Content:
1 Stück
Prices incl. VAT plus shipping costs net €23.53
Product information "Ledvance LED spotlight SPOT ADJUST 8W 930 PS DIM IP20 SI - 4058075799707"
Recessed spotlights for internal use, adjustable. Product properties: adjustable swivel angle: ± 25 °. Color rendering index R A : 90. Ray angle: 36 °. Aluminum die -cast housing. Springs with a soft silicone coating. Dimmable (at many standard dimmers, see also www.ledvance.de/dim ). Wiring through. Product advantages: Energy savings of up to 90 % compared to Halogenlampen spotlights. Powerselect: Adjustment of the brightness via DIP switches on the driver. Easy replacement of the external driver thanks to the plug with bayonet closure. Easy installation and electrical connection thanks to tool -free connection clamps. Scale design - great appearance, high -quality materials and small size fit in any environment. 5 years of guarantee. Areas of application: Direct replacement for recessed spotlights with halogen lamps. General lighting. Hotel room and corridore. Bars, restaurants. Accent lighting. Galleries, museums. Living rooms. Technical equipment: External ballast with DIP switches to adjust the power during installation. Renovation rings are available as accessories. Selected Dali 2.0 driver is available as an accessory.
Downloads & Documents
Login
Electrical data
| operating frequency: | 50-60 Hz |
|---|---|
| rated voltage: | 220-240 V |
| conformity: | CB, CE, EAC, ENEC, TÜV Süd, UKCA |
| lifetime: | 50000 h |
| system power: | 8 |
| switching cycles: | 100000 |
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| form type: | round |
| protection type: | IP20 |
| material: | aluminum |
| mounting: | ceiling mounting, Installation |
| impact resist: | IK03 |
| protection class: | II |
| environment temperature from: | -20 °C |
| environment temperature to: | 40 °C |
Photometric data
| radiation angle: | 36 ° |
|---|---|
| sensor: | no |
| dimmable: | yes |
| color code: | 830 |
| color: | silver |
| color temperature [Kelvin]: | 3000 |
| color rendering index [CRI]: | >90 |
| lamp type: | LED |
| lamp efficiency: | 85 lm/W |
| inclusive lamp: | yes |
| interface: | Phase cut |
| sensor type: | no |
| solar panel: | no |
| lum flux: | 680 lm |
Logistic data
| item category: | LED ceiling luminaires |
|---|
Dimensions & packaging
| EAN | 4058075799707 |
|---|---|
| Length | 100 mm |
| Width | 105 mm |
| Height | 85 mm |
| Weight | 400 g |
