Ledvance LED spotlight SPOT FIRE RATED 8W 930 PS DIM IP65 BK - 4058075799783
LEDVANCE
Ledvance LED spotlight SPOT FIRE RATED 8W 930 PS DIM IP65 BK - 4058075799783
Product number:
4058075799783
Immediately available
€26.72
Content:
1 Stück
Prices incl. VAT plus shipping costs net €22.45
Product information "Ledvance LED spotlight SPOT FIRE RATED 8W 930 PS DIM IP65 BK - 4058075799783"
Recessed spotlights for certain fire -retardant false ceilings, determined. Product properties: Color rendering index R a : 90. Protection class: IP65 (space side). Ray angle: 36 °. Aluminum die -cast housing. Fire protection source band already pre-installed. Springs with a soft silicone coating. Dimmable (at many standard dimmers, see also www.ledvance.de/dim ). Wiring through. Product advantages: fire -retardant: Developed and tested for use in certain fire -retardant false ceilings. Air density construction for reduced air clever and reduced energy loss. Powerselect: Adjustment of the brightness via DIP switches on the driver. Easy replacement of the external driver thanks to the plug with bayonet closure. Easy installation and electrical connection thanks to tool -free connection clamps. Scale design - great appearance, high -quality materials and small size fit in any environment. 5 years of guarantee. Areas of application: Direct replacement for recessed spotlights with halogen lamps. Fire -resistant blankets. Hotel room and corridore. Bars, restaurants. Galleries, museums. Technical equipment: External ballast with DIP switches to adjust the power during installation. Selected Dali 2.0 driver is available as an accessory.
Downloads & Documents
Login
Electrical data
| operating frequency: | 50-60 Hz |
|---|---|
| rated voltage: | 220-240 V |
| conformity: | CB, CE, EAC, ENEC, TÜV Süd, UKCA |
| lifetime: | 50000 h |
| system power: | 8 |
| switching cycles: | 100000 |
Casing
| ballproof: | no |
|---|---|
| fire protection: | no |
| form type: | round |
| protection type: | IP20/65 |
| material: | aluminum |
| mounting: | ceiling mounting, Installation |
| impact resist: | IK05 |
| protection class: | II |
| environment temperature from: | -20 °C |
| environment temperature to: | 40 °C |
Photometric data
| radiation angle: | 36 ° |
|---|---|
| sensor: | no |
| dimmable: | yes |
| color code: | 830 |
| color: | black |
| color temperature [Kelvin]: | 3000 |
| color rendering index [CRI]: | >90 |
| lamp type: | LED |
| lamp efficiency: | 85 lm/W |
| inclusive lamp: | yes |
| interface: | Phase cut |
| sensor type: | no |
| solar panel: | no |
| lum flux: | 680 lm |
Logistic data
| item category: | LED ceiling luminaires |
|---|
Dimensions & packaging
| EAN | 4058075799783 |
|---|---|
| Length | 100 mm |
| Width | 105 mm |
| Height | 85 mm |
| Weight | 410 g |
