PEHA Light Management Easyclick EnOcean Wall Transmitter STANDARD 4-Channel UP/DOWN White - 200413
PEHA Light Management Easyclick EnOcean Wall Transmitter STANDARD 4-Channel UP/DOWN White - 200413
Immediately available
€46.20
Prices incl. VAT plus shipping costs net €38.82
Product information "PEHA Light Management Easyclick EnOcean Wall Transmitter STANDARD 4-Channel UP/DOWN White - 200413"
Using the wireless 4-channel radio dual pushbutton wall transmitter of the STANDARD series by PEHA you can flexibly control your light. The transmitter is suitable for surface mounting. Open up a completely new comfort dimension for your home with EnOcean Easyclick, the innovative radio system from PEHA!
With the aid of the EnOcean Easyclick wall-mounted transmitters, you can easily control light from afar and even across rooms, manage lighting scenes, switch on panic lighting, control shutters and shutters, and control garage doors.
The radio transmission takes place on the European harmonized frequency of 868.3 MHz. The wall transmitter is particularly well suited for applications in which a flush mounted electrical installation is not desirable or possible, for example for renovations or retrofits of electrical installations or offices with mobile walls.
Loads can be wirelessly switched over receivers via pushing the button. The transmitters must be trained on the various receivers. Please refer to the respective user manual of the receiver. Each wall-mounted transmitter can drive an unlimited number of receivers.
The rounded down white housing is IP20 protected and has an UP/DOWN imprint at the top and at the bottom. The middle position is neutral.
The PEHA wall-mounted transmitters are to be supplemented with the 1- to 5-fold combination frames of the corresponding PEHA switch range. The combi frames are to be ordered separately - just scroll down to the cross-selling area at the bottom of the page.
Downloads & Documents
Instruction-manual-PEHA-Light-Management-Easyclick-EnOcean-Wall-Transmitter-STANDARD-4-Channel-D-80-455-02-FU-BLS-JR-00200413_1592176462_3
Bedienungsanleitung-PEHA-Lichtmanagement-Easyclick-EnOcean-Wandsender-STANDARD-4-Kanal-D-80-455-02-FU-BLS-JR-00200413_1592176457_5
Konformitaetserklaerung-PEHA-Lichtmanagement-Easyclick-EnOcean-Wandsender-STANDARD-4-Kanal-D-80-455-02-FU-BLS-JR-00200413_1592176457_6
Login
Electrical data
| conformity: | CE |
|---|---|
| switching cycles: | 50000 |
Casing
| protection type: | IP20 |
|---|---|
| mounting: | surface mounting |
| environment temperature from: | -25 °C |
| environment temperature to: | 65 °C |
Photometric data
| color: | white |
|---|---|
| interface: | EnOcean |
Logistic data
| item category: | light management |
|---|
Dimensions & packaging
| Length | 59 mm |
|---|---|
| Width | 59 mm |
| Height | 12 mm |
