Steinel IR Quattro HD COM1 - 4007841002794
Immediately available
€146.89
(32% saved)
€98.77
Content:
1 Stück
Prices incl. VAT plus shipping costs net €83.00
Product information "Steinel IR Quattro HD COM1 - 4007841002794"
Detection no finer! Infrared presence detector Presence Control PRO IR Quattro HD COM1 for indoors, ideal for medium to large-size offices, conference and meeting rooms, classrooms and lecture theatres, sports halls and warehouses, installation height up to 10 m, for switching light ON_ and OFF_, 4800 switching zones for the ultimate in detection quality, presence detection over a true 64 m2, square detection zone, mechanically scalable.
Downloads & Documents
STEINEL GmbH Dieselstr. 80-84 33442 Herzebrock-ClarholzDEinfo@steinel.dewww.steinel.de
Electrical data
| through wiring: | no |
|---|---|
| rated voltage: | 230 V |
| system power: | 2000 |
Casing
| ballproof: | no |
|---|---|
| form type: | square |
| protection type: | IP20 |
| mounting: | ceiling mounting |
| environment temperature from: | -25 °C |
| environment temperature to: | 55 °C |
Photometric data
| response brightness to: | 1000 Lux |
|---|---|
| response brightness from: | 10 Lux |
| detection angle: | 360 ° |
| color: | white |
| detection range: | 8 x 8 m (64 m²) |
| sensor type: | passive infrared |
| solar panel: | no |
| time setting to: | 30 min |
| time setting from: | 30 s |
Logistic data
| item category: | sensors |
|---|
Dimensions & packaging
| EAN | 4007841002794 |
|---|---|
| Length | 120 mm |
| Width | 70 mm |
| Height | 120 mm |
| Weight | 184 g |
