Trilux LED compact desktop luminaire CULTEGA T COM PAW 600-930 ETDI 01 - 7915259
Trilux GmbH & Co. KG
Trilux LED compact desktop luminaire CULTEGA T COM PAW 600-930 ETDI 01 - 7915259
Product number:
7915259
Shipping in 7 day(s)
€373.64
Content:
1 Stück
Prices incl. VAT plus shipping costs net €313.98
Product information "Trilux LED compact desktop luminaire CULTEGA T COM PAW 600-930 ETDI 01 - 7915259"
Compact desktop luminaire with flat, round luminaire head, three adjustment joints and a base. The luminaire is controlled via the operating elements on theluminaire head. Suitable for lighting an area RF3 according to DIN 5035-8 with up to 500lx without additional lighting. In combination with general lighting (500lx),modified illuminance levels according to DIN EN 12464-1:2021 of up to 1000lx are achieved for office-specific visual tasks in RF3 area. With baseplate for settingup on a flat surface. The baseplate is fully lined with felt to protect the standing surface. The vertical joint on the luminaire base enables the luminaire head to berotated by 120°. With prismatic cover for optimal light distribution. With direct asymmetric wide light distribution.. Glare evaluation according to UGR rating (EN12464-1) < 16. Luminaire luminous flux 700 lm, connected load 8,10 W, luminous efficiency of luminaire 86 lm/W. Light colour warm white, correlated colourtemperature (CCT) 3000 K, general colour rendering index (CRI) R a > 90. Colour locus tolerance (initial MacAdam) ≤ 3 SDCM, Mean rated service life L80(t q 25 °C) = 50,000 h. Luminaire body of die-cast aluminium. Surface fine-textured powder-coated, colour white. (RAL 9016). Baseplate dimensions: Ø 190 mm x 10 mm.Dimensions of luminaire head Ø 134 mm x 23 mm, Luminaire height (continuously adjustable) 390 mm - 715 mm. Weight: 2,8 kg. Safety class (EN 61140): II,protection rating (DIN EN 60529): IP20, impact resistance level in accordance with IEC 62262: IK02, testing temperature of wire glow test in accordance with IEC60695-2-11: 650 °C. The power adapter (Euro plug type C, EN 50075) is equipped with a connection cable and coupling for connection to the luminaire cable. Thecable routing is completely within the luminaire body, the connection cable is safely implemented via a plastic clamping device. The connection cable (1500 mm) atthe rear is connected to the connection cable of the power supply unit (1500 mm) by means of a plug connection. The total cable length of the connection is 3000mm. With electronic control gear unit, dimmable (integrated). The control gear unit is replaceable in accordance with the ecodesign requirements (VO (EU)2019/2020). Operation via 2 buttons (On/Off/brightness). The luminaire complies with the fundamental requirements of applicable EU regulations and productsafety legislation and bears the CE symbol.
Downloads & Documents
Login
Electrical data
| rated voltage: | 220-240 V |
|---|---|
| lifetime: | 50000 h |
| system power: | 8,1 |
Casing
| ballproof: | no |
|---|---|
| form type: | linear |
| protection type: | IP20 |
| material: | die-cast aluminium |
| mounting: | set up |
| impact resist: | IK02 |
| protection class: | II |
Photometric data
| sensor: | no |
|---|---|
| dimmable: | yes |
| dimming range to: | 100 % |
| dimming range from: | 1 % |
| color code: | 830 |
| color: | white |
| color temperature [Kelvin]: | 3000 |
| color rendering index [CRI]: | >90 |
| lamp efficiency: | 86 lm/W |
| inclusive lamp: | yes |
| lum flux: | 700 lm |
Logistic data
| item category: | desk luminaires |
|---|
Dimensions & packaging
| EAN | 4018242637416 |
|---|---|
| Length | 190 mm |
| Width | 190 mm |
| Height | 726 mm |
| Weight | 2800 g |
